PIC17C44T-16/PQ
RoHS
RoHS compliant
RoHS compliantPackage 44-QFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 16KB OTP 44MQFP
PDF
/
Inventory: 3197
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 2.35mm
Technical
CPU Family PIC
On Chip Program ROM Width 16
Address Bus Width 16
Number of Timers/Counters 8
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 16 μs
Watchdog Timer Yes
Bit Size 8
Supply Current-Max 24mA
Connectivity UART/USART
Program Memory Size 16KB 8K x 16
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 4.5V~6V
Memory Type EPROM
RAM Size 454 x 8
Number of I/O 33
Oscillator Type External
Memory Size 8kB
Interface SCI, UART, USART
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 6V
Pin Count 44
Base Part Number PIC17C44
Time@Peak Reflow Temperature-Max (s) 40
Frequency 16MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 17C
Published 1996
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-QFP
Mounting Type Surface Mount
