PIC17C43-25E/PQ
RoHS
RoHS compliant
RoHS compliantPackage 44-QFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU OTP 4KX16 PWM 44-MQFP
PDF
/
Inventory: 1794
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Programmable I/O 33
Max Frequency 25MHz
Core Architecture PIC
Number of Timers/Counters 8
Data Bus Width 8b
Access Time 25 μs
Watchdog Timer Yes
Connectivity UART/USART
Program Memory Size 8KB 4K x 16
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 4.5V~6V
Memory Type EPROM
RAM Size 454 x 8
Speed 25MHz
Number of I/O 33
Oscillator Type External
Memory Size 4kB
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface SCI, UART, USART
Base Part Number PIC17C43
Frequency 25MHz
Max Power Dissipation 1W
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series PIC? 17C
Published 1996
Packaging Tray
Operating Temperature -40°C~125°C TA
Physical
Supplier Device Package 44-MQFP (10x10)
Number of Pins 44
Package / Case 44-QFP
Mounting Type Surface Mount
