PIC17C43-25E/L

Microchip Technology
RoHS
RoHS RoHS compliant
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU OTP 4KX16 PWM 44PLCC
PDF
/
Inventory: 3746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Number of Programmable I/O 33
Max Frequency 25MHz
Core Architecture PIC
Number of Timers/Counters 4
Data Bus Width 8b
Access Time 25 μs
Watchdog Timer Yes
Connectivity UART/USART
Program Memory Size 8KB 4K x 16
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 4.5V~6V
Memory Type EPROM
RAM Size 454 x 8
Speed 25MHz
Number of I/O 33
Oscillator Type External
Memory Size 4kB
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface SCI, UART, USART
Base Part Number PIC17C43
Frequency 25MHz
Max Power Dissipation 1W
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series PIC? 17C
Published 1996
Packaging Tube
Operating Temperature -40°C~125°C TA

Physical

Supplier Device Package 44-PLCC (16.59x16.59)
Number of Pins 44
Package / Case 44-LCC (J-Lead)
Mounting Type Surface Mount
