PIC16LF88-I/P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 7KB Flash 2.5V/3.3V/5V 18-Pin PDIP Tube
PDF
/
Buying Options
Total Price: USD $3.98
Unit Price: USD $3.9776
≥1 USD $3.9776
Inventory: 633
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 18-DIP (0.300, 7.62mm)
Number of Pins 18
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? 16F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature OPERATES AT 2V MINIMUM SUPPLY @ 4 MHZ
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 20MHz
Base Part Number PIC16LF88
Pin Count 18
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.5/5V
Supply Voltage-Min (Vsup) 3V
Interface I2C, SPI, SSP, UART, USART
Memory Size 7kB
Oscillator Type Internal
Number of I/O 16
RAM Size 368 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 8
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Supply Current-Max 4mA
Bit Size 8
Data Converter A/D 7x10b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 3
ROM (words) 4096
EEPROM Size 256 x 8
CPU Family PIC
Number of ADC Channels 7
Number of PWM Channels 1
Dimensions
Height 3.68mm
Length 22.99mm
Width 6.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
