PIC16LF76-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 14KB FLASH 28SOIC
PDF
/
Buying Options
Total Price: USD $5.24
Unit Price: USD $5.2448
≥1 USD $5.2448
Inventory: 163
Minimum: 1
-
+
Technical Details
Technical
Core Size 8-Bit
Program Memory Size 14KB 8K x 14
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 5x8b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 3
Address Bus Width 8b
Density 112 kb
On Chip Program ROM Width 14
CPU Family PIC
Number of ADC Channels 5
Number of PWM Channels 2
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Number of Bits 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5.5V
RAM Size 368 x 8
Speed 10 MHz
Nominal Supply Current 400μA
Number of I/O 22
Oscillator Type External
Memory Size 14kB
Interface I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 3V
Pin Count 28
Base Part Number PIC16LF76
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16F
Packaging Tube
Operating Temperature -40°C~85°C TA
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
