PIC16LF722-E/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 3.5KB Flash 2.5V/3.3V 28-Pin QFN EP Tube
PDF
/
Buying Options
Total Price: USD $21.1
Unit Price: USD $21.0976
≥1 USD $21.0976
≥10 USD $17.3109
≥100 USD $16.77035
≥500 USD $16.22885
≥1000 USD $15.6883
Inventory: 1630
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-VQFN Exposed Pad
Number of Pins 28
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2008
Series PIC? XLP? 16F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LF722
Pin Count 28
Interface I2C, SCI, SPI, UART, USART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 25
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Number of Bits 8
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 11x8b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 3
CPU Family PIC
Number of ADC Channels 11
Number of PWM Channels 2
Number of USB Channels 1
Dimensions
Height 939.8μm
Length 5.9944mm
Width 5.9944mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
