PIC16LF19176-I/P
RoHS
/
Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 28KB FLASH 40DIP
PDF
/
Buying Options
Total Price: USD $2.63
Unit Price: USD $2.6312
≥1 USD $2.6312
≥10 USD $2.42
≥100 USD $2.2
Inventory: 764
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 40-DIP (0.600, 15.24mm)
Surface Mount NO
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Terminal Finish Matte Tin (Sn)
Additional Feature IT ALSO OPERATES AT 1.8V MIN AT 16 MHZ
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC16LF19176
JESD-30 Code R-PDIP-T40
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type Internal
Number of I/O 35
Speed 32MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LCD, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 28KB 16K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 31x12b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 256 x 8
On Chip Program ROM Width 14
Dimensions
Length 51.7525mm
Width 15.24mm
Compliance
RoHS Status Non-RoHS Compliant
