PIC16LF19175T-I/MV
RoHS
RoHS compliant
RoHS compliantPackage 40-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
RoHS Compliant NO LEAD QUAD CMOS Microcontroller -40C~85C TA 32MHz 0.55mm 1K x 8
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.8568
≥1 USD $1.8568
≥10 USD $1.6984
≥100 USD $1.54
Inventory: 1287
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Surface Mount
Package / Case 40-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
Terminal Finish Matte Tin (Sn)
Additional Feature IT ALSO OPERATES AT 1.8V MIN AT 16 MHZ
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.4mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC16LF19175
JESD-30 Code S-PQCC-N40
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type Internal
Number of I/O 35
Speed 32MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LCD, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 14KB 8K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 31x12b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 256 x 8
On Chip Program ROM Width 14
Dimensions
Height Seated (Max) 0.55mm
Length 5mm
Width 5mm
Compliance
RoHS Status RoHS Compliant
