PIC16LF18875-E/MV
RoHS
RoHS compliant
RoHS compliantPackage 40-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 14KB FLASH 40UQFN
PDF
/
Inventory: 3666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 14KB 8K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 35x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 8192
EEPROM Size 256 x 8
On Chip Program ROM Width 14
Screening Level ISO/TS-16949
Integrated Cache NO
RAM (words) 1024
Number of Timers 7
On Chip Data RAM Width 8
RAM Size 1K x 8
Number of I/O 36
Oscillator Type Internal
Memory Size 14kB
Interface I2C, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQCC-N40
Base Part Number PIC16LF18875
Frequency 32MHz
Terminal Pitch 0.4mm
Supply Voltage 3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Additional Feature ALSO OPERATES AT 1.8 V SUPPLY AT 16 MHZ
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series PIC? XLP? 16F
Published 2016
Packaging Tube
Operating Temperature -40°C~125°C TA
Dimensions
Height Seated (Max) 0.55mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case 40-UFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
