PIC16LF18854T-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller -40C~85C TA 32MHz 2mm 512x 8
PDF
/
Inventory: 3290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 10.2mm
Height Seated (Max) 2mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 14
EEPROM Size 256 x 8
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 24x10b; D/A 1x5b
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 512 x 8
Speed 32MHz
Number of I/O 25
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code R-PDSO-G28
Base Part Number PIC16LF18854
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
HTS Code 8542.31.00.01
Additional Feature ALSO OPEARTES AT 16 MHZ AT 1.8V MINIMUM SUPPLY
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series PIC? XLP? 16F
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
