PIC16LF1825-I/P
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 14KB Flash 2.5V/3.3V 14-Pin PDIP
PDF
/
Buying Options
Total Price: USD $1.7
Unit Price: USD $1.6984
≥1 USD $1.6984
≥10 USD $1.5488
≥100 USD $1.4168
Inventory: 585
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 14
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2010
Series PIC? XLP? mTouch? 16F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code 3A001.A.3
Terminal Finish MATTE TIN
Additional Feature ALSO OPERATES 1.8V MINIMUM SUPPLY AT 16 MHZ
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 3V
Frequency 32MHz
Base Part Number PIC16LF1825
Pin Count 14
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Interface I2C, LIN, SPI, UART, USART
Memory Size 14kB
Oscillator Type Internal
Number of I/O 11
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 14KB 8K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
DAC Channels YES
Number of Timers/Counters 5
ROM (words) 8192
EEPROM Size 256 x 8
On Chip Program ROM Width 14
CPU Family PIC
Number of Programmable I/O 12
Number of PWM Channels 4
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
