PIC16LF1788-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Microchip Technology 8-bit Microcontrollers - MCU 28KB Flash 2KB RAM 256B EEPROM
PDF
/
Inventory: 1435
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Height Seated (Max) 2.65mm
Technical
Screening Level TS 16949
CPU Family PIC
On Chip Program ROM Width 14
EEPROM Size 256 x 8
ROM (words) 16384
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 11x12b; D/A 1x8b, 3x5b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 28KB 16K x 14
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, POR, PSMC, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 2K x 8
Speed 32MHz
Number of I/O 24
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 2/3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Base Part Number PIC16LF1788
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Additional Feature IT ALSO OPERATES AT 1.8V AT 16MHZ
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2013
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
