PIC16LF1703-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MICROCHIP PIC16LF1703-I/SL8 Bit Microcontroller, Flash, PIC16LF17xx, 32 MHz, 3.5 KB, 256 Byte, 14 Pins, SOIC
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.968
≥1 USD $0.968
≥10 USD $0.8976
≥100 USD $0.8008
Inventory: 906
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Weight 338.011364mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2013
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Matte Tin (Sn)
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LF1703
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, LIN, RS-232, SPI
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 12
Nominal Supply Current 8μA
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, LINbus, SPI
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 3
Address Bus Width 8b
Number of ADC Channels 8
Number of I2C Channels 1
Dimensions
Height 1.5mm
Length 8.65mm
Width 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
