PIC16LF1566-E/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 14KB FLASH 28SDIP
PDF
/
Inventory: 2903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 34.67mm
Height Seated (Max) 5.08mm
Technical
On Chip Data RAM Width 8
Number of External Interrupts 1
Number of Timers 4
Number of Serial I/Os 1
RAM (words) 1024
Integrated Cache NO
Format FIXED-POINT
Low Power Mode YES
Boundary Scan NO
On Chip Program ROM Width 14
ROM (words) 8192
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 23x10b
Bit Size 8
Supply Current-Max 3.5mA
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 14KB 8K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 1K x 8
Number of I/O 25
Oscillator Type Internal
Memory Size 14kB
Interface I2C, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code R-PDIP-T28
Base Part Number PIC16LF1566
Frequency 32MHz
Terminal Pitch 2.54mm
Supply Voltage 3V
Terminal Position DUAL
Technology CMOS
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2016
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Surface Mount NO
Package / Case 28-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 6 Weeks
