PIC16LF15376T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 28KB FLASH 44TQFP
PDF
/
Buying Options
Total Price: USD $1.64
Unit Price: USD $1.6368
≥1 USD $1.6368
≥10 USD $1.496
≥100 USD $1.3552
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 44-TQFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series PIC? XLP? 16F
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Additional Feature ALSO OPERATES AT 1.8 V MINIMUM SUPPLY AT 16 MHZ
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3V
Terminal Pitch 0.8mm
Base Part Number PIC16LF15376
JESD-30 Code S-PQFP-G44
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type Internal
Number of I/O 36
Speed 32MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 28KB 16K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 35x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 16384
EEPROM Size 224 x 8
On Chip Program ROM Width 14
CPU Family PIC
Screening Level TS 16949
Integrated Cache NO
RAM (words) 2048
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
