PIC16LF15324-E/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 14SOIC
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.9064
≥1 USD $0.9064
≥10 USD $0.8272
≥100 USD $0.748
Inventory: 887
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Series PIC? XLP? 16F
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Additional Feature ALSO OPERATES WITH 1.8VMIN @16MHZ
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3V
Terminal Pitch 1.27mm
Base Part Number PIC16LF15324
JESD-30 Code R-PDSO-G14
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type Internal
Number of I/O 12
Speed 32MHz
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 11x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
EEPROM Size 224 x 8
On Chip Program ROM Width 14
Screening Level TS 16949
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
