PIC16LF1527-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 14KB Flash RAM 768b nanoWatt
PDF
/
Buying Options
Total Price: USD $2.51
Unit Price: USD $2.505862
≥1 USD $2.505862
≥10 USD $2.364028
≥100 USD $2.230211
≥500 USD $2.103973
≥1000 USD $1.98488
Inventory: 937
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 9mm
Length 9mm
Height 950μm
Technical
Number of I2C Channels 2
Number of PWM Channels 10
Number of ADC Channels 30
Number of Programmable I/O 53
Number of A/D Converters 1
CPU Family PIC
Address Bus Width 8b
Number of Timers/Counters 9
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 30x10b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 28KB 16K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Number of Bits 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 1.5K x 8
Nominal Supply Current 300μA
Number of I/O 54
Oscillator Type Internal
Memory Size 28kB
Interface I2C, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 64
Base Part Number PIC16LF1527
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
