PIC16LC781T-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 1.75KB 128RAM 16 I/O
PDF
/
Inventory: 8307
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2001
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LC781
Pin Count 20
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface EBI/EMI, SPI, UART, USART
Memory Size 1.8kB
Oscillator Type Internal
Number of I/O 13
RAM Size 128 x 8
Memory Type EPROM, ROMless
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 1.75KB 1K x 14
Bit Size 8
Data Converter A/D 8x8b; D/A 1x8b
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 2
On Chip Program ROM Width 14
Number of Programmable I/O 16
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
