PIC16LC73B-04/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB OTP 28SDIP
PDF
/
Inventory: 968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 28-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 28
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 1997
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Supply Voltage 3V
Terminal Pitch 2.54mm
Frequency 4MHz
Base Part Number PIC16LC73B
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, SPI, UART, USART
Memory Size 7kB
Oscillator Type External
Number of I/O 22
RAM Size 192 x 8
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 5x8b
Watchdog Timer Yes
Access Time 4 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
On Chip Program ROM Width 14
CPU Family PIC
Dimensions
Height Seated (Max) 4.06mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
