PIC16LC73AT-04/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB OTP 28SOIC
PDF
/
Inventory: 5766
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.5V~6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 5x8b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
On Chip Program ROM Width 14
CPU Family PIC
RAM Size 192 x 8
Number of I/O 22
Oscillator Type External
Memory Size 7kB
Interface I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 6V
Pin Count 28
Base Part Number PIC16LC73A
Time@Peak Reflow Temperature-Max (s) 40
Frequency 4MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Dimensions
Height Seated (Max) 2.642mm
Length 17.894mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
