PIC16LC72AT-04I/ML

Microchip Technology
RoHS
RoHS RoHS compliant
Package 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 8BIT 3.5KB OTP 28QFN
PDF
/
Inventory: 5162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Number of Programmable I/O 22
Max Frequency 4MHz
Core Architecture PIC
Number of Timers/Counters 8
Data Bus Width 8b
Access Time 4 μs
Watchdog Timer Yes
Data Converter A/D 5x8b
Connectivity I2C, SPI
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
Memory Type EPROM
RAM Size 128 x 8
Speed 4MHz
Number of I/O 22
Oscillator Type External
Memory Size 3.5kB
Min Supply Voltage 2.5V
Max Supply Voltage 5.5V
Interface I2C, SPI, SSP
Base Part Number PIC16LC72A
Frequency 4MHz
Max Power Dissipation 1W
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PIC? 16C
Published 1999
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Supplier Device Package 28-QFN (6x6)
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
