PIC16LC717/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 3.5KB EPROM 3.3V/5V 18-Pin SOIC W Tube
PDF
/
Inventory: 8419
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 2.64mm
Technical
Number of Programmable I/O 16
CPU Family PIC
On Chip Program ROM Width 14
ROM (words) 2048
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 20 μs
Watchdog Timer Yes
Data Converter A/D 6x10b
Bit Size 8
Connectivity I2C, SPI
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
Memory Type EPROM
RAM Size 256 x 8
Number of I/O 15
Oscillator Type Internal
Memory Size 3.5kB
Interface I2C, SPI, SSP
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 18
Base Part Number PIC16LC717
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Additional Feature CAN ALSO OPERATE AT 2.5V MIN SUPPLY
Terminal Finish Matte Tin (Sn)
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 2002
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 18
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
