PIC16LC717-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 3.5KB 256 RAM 16 I/O
PDF
/
Buying Options
Total Price: USD $3.37
Unit Price: USD $3.367589
≥1 USD $3.367589
≥200 USD $1.30371
≥500 USD $1.257758
≥1000 USD $1.235439
Inventory: 1464
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2002
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Terminal Finish MATTE TIN
Additional Feature CAN ALSO OPERATE AT 2.5V MIN SUPPLY
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LC717
Pin Count 18
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, SPI, SSP
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 15
RAM Size 256 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, SPI
Bit Size 8
Data Converter A/D 6x10b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 1
Number of Programmable I/O 16
Dimensions
Height Seated (Max) 2.64mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
