PIC16LC715-04I/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU OTP 2KX14 A/D PWM 18SOIC
PDF
/
Inventory: 2257
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 18
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1997
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LC715
Pin Count 18
Operating Supply Voltage 5V
Memory Size 3.5kB
Oscillator Type External
Number of I/O 13
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Supply Current-Max 3.8mA
Bit Size 8
Data Converter A/D 4x8b
Watchdog Timer Yes
Access Time 4 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 2048
On Chip Program ROM Width 14
CPU Family PIC
Dimensions
Height Seated (Max) 2.642mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
