PIC16LC64A-04I/P
RoHS
RoHS compliant
RoHS compliantPackage 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB OTP 40DIP
PDF
/
Buying Options
Total Price: USD $7.01
Unit Price: USD $7.0136
≥1 USD $7.0136
Inventory: 274
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 52.07mm
Height Seated (Max) 5.715mm
Technical
CPU Family PIC
On Chip Program ROM Width 14
ROM (words) 2048
Number of Timers/Counters 3
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 4 μs
Watchdog Timer Yes
Bit Size 8
Connectivity I2C, SPI
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~6V
RAM Size 128 x 8
Number of I/O 33
Oscillator Type External
Memory Size 3.5kB
Interface I2C, SPI, USART
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 6V
Pin Count 40
Base Part Number PIC16LC64A
Frequency 4MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 1997
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 40
Surface Mount NO
Package / Case 40-DIP (0.600, 15.24mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 5 Weeks
