PIC16LC621T-04E/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.75KB OTP 18SOIC
PDF
/
Inventory: 3378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of I/O 13
RAM Size 80 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.5V~6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 1.75KB 1K x 14
Supply Current-Max 2mA
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 8
ROM (words) 1024
On Chip Program ROM Width 14
CPU Family PIC
Oscillator Type External
Memory Size 1kB
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 6V
Pin Count 18
Base Part Number PIC16LC621
Time@Peak Reflow Temperature-Max (s) 40
Frequency 4MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Dimensions
Height Seated (Max) 2.64mm
Length 11.53mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Surface Mount YES
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
