PIC16LC58BT-04/SO

Microchip Technology
RoHS
RoHS RoHS compliant
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 8BIT 3KB OTP 18SOIC
PDF
/
Inventory: 8477
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Supply Voltage 5V
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LC58B
Pin Count 18
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Memory Size 2kB
Oscillator Type External
Number of I/O 12
RAM Size 73 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3KB 2K x 12
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 2048
On Chip Program ROM Width 12
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Terminal Finish Matte Tin (Sn)
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA

Dimensions

Height Seated (Max) 2.64mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Surface Mount YES
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
