PIC16LC54AT-04E/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 768B OTP 18SOIC
PDF
/
Inventory: 9784
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2002
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16LC54A
Pin Count 18
Supply Voltage-Max (Vsup) 6.25V
Supply Voltage-Min (Vsup) 3V
Memory Size 512B
Oscillator Type External
Number of I/O 12
RAM Size 25 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 3V~6.25V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 768B 512 x 12
Supply Current-Max 25mA
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 512
On Chip Program ROM Width 12
Dimensions
Height Seated (Max) 2.64mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
