PIC16HV610-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.75KB FLASH 14SOIC
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0736
≥1 USD $1.0736
≥10 USD $0.968
≥100 USD $0.924
Inventory: 502
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 8.65mm
Height 1.5mm
Technical
Number of PWM Channels 4
CPU Family PIC
Density 14 kb
Number of Timers/Counters 2
DAC Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Bit Size 8
Program Memory Size 1.75KB 1K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, WDT
Core Processor PIC
Number of Bits 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5V
RAM Size 64 x 8
Number of I/O 11
Oscillator Type Internal
Memory Size 1.8kB
Interface RS-232, USB
Supply Voltage-Max (Vsup) 5.5V
Pin Count 14
Base Part Number PIC16HV610
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16F
Published 2006
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
