PIC16HV540-04I/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 1.5KB EPROM 5V/9V/12V 20-Pin SSOP Tube
PDF
/
Inventory: 5400
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1999
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 9V
Terminal Pitch 0.65mm
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16HV540
Pin Count 20
Supply Voltage-Min (Vsup) 3.5V
Memory Size 1.5kB
Oscillator Type External
Number of I/O 12
RAM Size 25 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 3.5V~15V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 768B 512 x 12
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 512
On Chip Program ROM Width 12
CPU Family PIC
Dimensions
Height Seated (Max) 2mm
Length 7.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
