PIC16F84AT-20E/SS

Microchip Technology
RoHS
RoHS RoHS compliant
Package 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU CMOS 20MHZ 1K FLSH 20SSOP
PDF
/
Inventory: 2082
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Supplier Device Package 20-SSOP

Technical

Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 1997
Series PIC? 16F
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Max Power Dissipation 800mW
Frequency 20MHz
Base Part Number PIC16F84A
Max Supply Voltage 5.5V
Min Supply Voltage 4V
Memory Size 1.8kB
Oscillator Type External
Number of I/O 13
Speed 20MHz
RAM Size 68 x 8
Memory Type FLASH
Voltage - Supply (Vcc/Vdd) 4V~5.5V
Core Processor PIC
Peripherals POR, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 1.75KB 1K x 14
Watchdog Timer Yes
Access Time 20 μs
Data Bus Width 8b
Number of Timers/Counters 8
Core Architecture PIC
EEPROM Size 64 x 8
Max Frequency 20MHz
Number of Programmable I/O 13

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
