PIC16F747-E/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 44QFN
PDF
/
Inventory: 911
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-VQFN Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 1997
Series PIC? 16F
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F747
Pin Count 44
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5.5V
Supply Voltage-Min (Vsup) 4V
Interface I2C, SPI, UART, USART
Memory Size 7kB
Oscillator Type Internal
Number of I/O 36
RAM Size 368 x 8
Voltage - Supply (Vcc/Vdd) 4V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Supply Current-Max 5mA
Bit Size 8
Data Converter A/D 14x10b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
On Chip Program ROM Width 14
CPU Family PIC
Dimensions
Height Seated (Max) 1mm
Length 8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
