PIC16F716-I/P4AP
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 176
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 22.88mm
Height Seated (Max) 5.334mm
Technical
ROM Programmability FLASH
Screening Level TS 16949
On Chip Program ROM Width 14
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Bit Size 8
Clock Frequency 20MHz
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Speed 20 MHz
Number of I/O 13
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
JESD-30 Code R-PDIP-T18
Pin Count 18
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Technology CMOS
Additional Feature OPERTES AT 3 V MINIMUM SUPPLY @ 10 MHZ AND 2 V MINIMUM SUPPLY @ 4 MHZ
Terminal Finish Matte Tin (Sn)
Number of Terminations 18
Pbfree Code yes
JESD-609 Code e3
Physical
Surface Mount NO
