PIC16F636T-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU FLASH 2KX14 14TSSOP
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.804
≥1 USD $1.804
Inventory: 1374
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
Series PIC? 16F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F636
Pin Count 14
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface RS-232, SPI, USB
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 11
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, LVD, POR, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Bit Size 8
Watchdog Timer Yes
Access Time 20 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 2
On Chip Program ROM Width 14
CPU Family PIC
Number of Programmable I/O 12
Dimensions
Height Seated (Max) 1.1mm
Length 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
