PIC16F630-I/STG
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 1.75KB 64 RAM 12 I/O Lead Free Package
PDF
/
Buying Options
Total Price: USD $15.27
Unit Price: USD $15.27125
≥1 USD $15.27125
≥10 USD $12.5305
≥100 USD $12.1391
≥500 USD $11.7477
≥1000 USD $11.3563
Inventory: 1728
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 5mm
Technical
RAM (bytes) 64
Number of Programmable I/O 12
On Chip Program ROM Width 14
Core Architecture PIC
Number of Timers/Counters 2
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Frequency (Max) 20MHz
Bit Size 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Memory Type FLASH
RAM Size 64B
Number of I/O 12
Memory Size 1.8kB
Min Supply Voltage 2V
Max Supply Voltage 5.5V
Interface RS-232, USB
Temperature Grade INDUSTRIAL
Qualification Status Not Qualified
Pin Count 14
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
Number of Pins 14
Package / Case TSSOP
Mount Surface Mount
