PIC16F526-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.5KB FLASH 14SOIC
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.8712
≥1 USD $0.8712
≥10 USD $0.7832
≥100 USD $0.7128
Inventory: 854
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 8.65mm
Height 1.5mm
Technical
Number of ADC Channels 3
Number of Programmable I/O 12
Number of A/D Converters 1
CPU Family PIC
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 3x8b
Bit Size 8
Supply Current-Max 2.2mA
Program Memory Size 1.5KB 1K x 12
Core Size 8-Bit
Program Memory Type FLASH
Peripherals POR, WDT
Core Processor PIC
Number of Bits 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5.5V
RAM Size 67 x 8
Number of I/O 11
Oscillator Type Internal
Memory Size 1.5kB
Voltage 5V
Pin Count 14
Base Part Number PIC16F526
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 700mW
Subcategory Microcontrollers
Additional Feature ALSO OPERATES AT 2V MINIMUM SUPPLY FOR 4 MHZ
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16F
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
