PIC16F18346-I/GZ
RoHS
RoHS compliant
RoHS compliantPackage 20-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 28KB FLASH 20UQFN
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.276
≥1 USD $1.276
≥10 USD $1.1704
≥100 USD $1.056
Inventory: 3087
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2011
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3V
Terminal Pitch 0.5mm
Base Part Number PIC16F18346
JESD-30 Code S-PQCC-N20
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.3V
Oscillator Type Internal
Number of I/O 18
Speed 32MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 28KB 16K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 2.9mA
Bit Size 8
Data Converter A/D 17x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 16384
EEPROM Size 256 x 8
On Chip Program ROM Width 14
Boundary Scan NO
Low Power Mode YES
Format FIXED POINT
Integrated Cache NO
RAM (words) 2048
Number of Serial I/Os 1
Number of Timers 7
Number of External Interrupts 1
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 0.55mm
Length 4mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
