PIC16F18326T-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED POINT ROHS3Compliant GULL WING DUAL Microcontroller -40C~85C TA 2.9mA 32MHz 1.75mm
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.1616
≥1 USD $1.1616
≥10 USD $1.0648
≥100 USD $0.9592
Inventory: 1262
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
On Chip Data RAM Width 8
Number of External Interrupts 1
Number of Timers 7
Number of Serial I/Os 1
RAM (words) 2048
Integrated Cache NO
Format FIXED POINT
Low Power Mode YES
Boundary Scan NO
On Chip Program ROM Width 14
EEPROM Size 256 x 8
ROM (words) 16384
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 11x10b; D/A 1x5b
Bit Size 8
Supply Current-Max 2.9mA
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 28KB 16K x 14
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 2K x 8
Speed 32MHz
Number of I/O 12
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.3V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-G14
Base Part Number PIC16F18326
Terminal Pitch 1.27mm
Supply Voltage 3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
