PIC16F1829-I/GZ
RoHS
RoHS compliant
RoHS compliantPackage 20-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-Bit PIC16 PIC RISC 14KB Flash 3.3V/5V 20-Pin UQFN EP Tube
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6456
≥1 USD $1.6456
≥10 USD $1.496
≥100 USD $1.3464
Inventory: 473
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2004
Series PIC? XLP? mTouch? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 32MHz
Base Part Number PIC16F1829
JESD-30 Code S-PQCC-N20
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 14kB
Oscillator Type Internal
Number of I/O 17
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 14KB 8K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 4.5mA
Bit Size 8
Data Converter A/D 12x10b
Has ADC YES
DMA Channels NO
PWM Channels YES
ROM (words) 8192
EEPROM Size 256 x 8
CPU Family PIC
Dimensions
Length 4mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
