PIC16F1824-E/ML
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 16QFN
PDF
/
Buying Options
Total Price: USD $9.86
Unit Price: USD $9.8632
≥1 USD $9.8632
≥10 USD $9.304913
≥100 USD $8.778217
≥500 USD $8.281335
≥1000 USD $7.812589
Inventory: 1386
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 4mm
Height 950μm
Technical
Number of I2C Channels 2
Number of ADC Channels 8
Number of UART Channels 1
CPU Family PIC
EEPROM Size 256 x 8
ROM (words) 4096
Number of Timers/Counters 5
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Supply Current-Max 3.4mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 256 x 8
Number of I/O 11
Oscillator Type Internal
Memory Size 7kB
Interface I2C, SPI, UART, USART
Pin Count 16
Base Part Number PIC16F1824
Frequency 32MHz
Supply Voltage 3V
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PIC? XLP? mTouch? 16F
Published 2010
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
