PIC16F1823-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 14TSSOP
PDF
/
Buying Options
Total Price: USD $2.86
Unit Price: USD $2.857
≥1 USD $2.857
≥10 USD $2.527346
≥100 USD $2.331123
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 13
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 14
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series PIC? XLP? 16F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.3V
Terminal Pitch 0.65mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F1823
Pin Count 14
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 12
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 3
EEPROM Size 256 x 8
CPU Family PIC
Number of ADC Channels 8
Number of I2C Channels 1
Dimensions
Height 1.05mm
Length 5.1mm
Width 4.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
