PIC16F1789-E/MV
RoHS
RoHS compliant
RoHS compliantPackage 40-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC RISC 28KB Flash 3.3V/5V Automotive 40-Pin UQFN EP Tube
PDF
/
Buying Options
Total Price: USD $16.11
Unit Price: USD $16.10915
≥1 USD $16.10915
≥10 USD $13.2183
≥100 USD $12.80505
≥500 USD $12.3918
≥1000 USD $11.97855
Inventory: 155
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature IT ALSO OPERATES AT 2.3V AT 16MHZ
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F1789
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.5/5V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type Internal
Number of I/O 35
Speed 32MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PSMC, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 28KB 16K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2013
Packaging Tube
Operating Temperature -40°C~125°C TA
Bit Size 8
Data Converter A/D 14x12b; D/A 1x8b, 3x5b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 16384
EEPROM Size 256 x 8
On Chip Program ROM Width 14
CPU Family PIC
Screening Level TS 16949
Physical
Number of Pins 40
Surface Mount YES
Package / Case 40-UFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
Dimensions
Height Seated (Max) 0.55mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
