PIC16F1784-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 44QFN
PDF
/
Buying Options
Total Price: USD $1.97
Unit Price: USD $1.9712
≥1 USD $1.9712
Inventory: 57
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Height 950μm
Technical
Number of I2C Channels 1
Number of ADC Channels 14
RAM (words) 512
Integrated Cache NO
Number of Programmable I/O 36
EEPROM Size 256 x 8
ROM (words) 4096
Address Bus Width 8b
Number of Timers/Counters 3
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 14x12b; D/A 1x8b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PSMC, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 512 x 8
Nominal Supply Current 2.1mA
Number of I/O 35
Oscillator Type Internal
Memory Size 7kB
Interface I2C, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number PIC16F1784
Time@Peak Reflow Temperature-Max (s) 40
Frequency 32MHz
Terminal Pitch 0.65mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
