PIC16F1782-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 28SOIC
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.8216
≥100 USD $1.6456
Inventory: 1782
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2004
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Number of USB Channels 0
Number of I2C Channels 1
Number of PWM Channels 2
Number of ADC Channels 11
CPU Family PIC
EEPROM Size 256 x 8
Address Bus Width 8b
Number of Timers/Counters 3
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 11x12b; D/A 1x8b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PSMC, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 256 x 8
Nominal Supply Current 2.1mA
Number of I/O 24
Oscillator Type Internal
Memory Size 3.5kB
Interface I2C, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 5.5V
Pin Count 28
Base Part Number PIC16F1782
Time@Peak Reflow Temperature-Max (s) 40
Frequency 32MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.5mm
Length 17.9mm
Height 2.05mm
