PIC16F1709-E/ML
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 14KB FLASH 20QFN
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.5576
≥1 USD $1.5576
≥10 USD $1.4344
≥100 USD $1.3024
Inventory: 562
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 4mm
Height 750μm
Technical
Number of USB Channels 0
Number of PWM Channels 2
Number of ADC Channels 12
Number of UART Channels 1
Number of Timers/Counters 5
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 12x10b; D/A 1x8b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 14KB 8K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 1K x 8
Number of I/O 18
Oscillator Type Internal
Memory Size 14kB
Interface I2C, LIN, RS-232, SPI, UART, USART
Base Part Number PIC16F1709
Time@Peak Reflow Temperature-Max (s) 40
Frequency 32MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2010
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Weight 57.09594mg
Number of Pins 20
Package / Case 20-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
