PIC16F1708T-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC RISC 7KB Flash 3.3V/5V Automotive 20-Pin SOIC W T/R
PDF
/
Inventory: 6548
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2013
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F1708
Operating Supply Voltage 5.5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 7kB
Oscillator Type Internal
Number of I/O 18
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 12x10b; D/A 1x8b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 5
ROM (words) 4096
CPU Family PIC
Number of UART Channels 1
Number of ADC Channels 12
Number of PWM Channels 2
Dimensions
Height 2.35mm
Length 8.65mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
