PIC16F1707T-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller 2.5/5V -40C~85C TA 32MHz 1.75mm
PDF
/
Inventory: 4184
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2013
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 1.27mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F1707
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.5/5V
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, LIN, RS-232, SPI, UART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 18
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
Number of ADC Channels 8
Number of UART Channels 0
CPU Family PIC
Number of Timers/Counters 3
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Connectivity I2C, LINbus, SPI
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.75mm
Length 8.65mm
Height 1.75mm
