PIC16F1707-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MICROCHIP PIC16F1707-I/SOMICROCONTROLLER MCU, 8 BIT, PIC16, 32MHZ, SOIC-20
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.276
≥100 USD $1.144
Inventory: 417
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2013
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F1707
Supply Voltage-Max (Vsup) 5.5V
Interface I2C, LIN, RS-232, SPI, UART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 18
Nominal Supply Current 8μA
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, LINbus, SPI
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 3
Address Bus Width 8b
CPU Family PIC
Number of UART Channels 0
Number of ADC Channels 8
Number of PWM Channels 2
Dimensions
Height 2.35mm
Length 12.8mm
Width 7.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
