PIC16F1705-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 14KB FLASH 14TSSOP
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.1088
≥100 USD $0.9944
Inventory: 1629
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.5mm
Length 5.1mm
Height 1.05mm
Technical
Number of USB Channels 0
Number of I2C Channels 1
Number of PWM Channels 2
Number of ADC Channels 8
CPU Family PIC
Address Bus Width 8b
Number of Timers/Counters 5
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b; D/A 1x8b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 14KB 8K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 1K x 8
Nominal Supply Current 8μA
Number of I/O 12
Oscillator Type Internal
Memory Size 14kB
Interface I2C, LIN, RS-232, SPI, UART, USART
Base Part Number PIC16F1705
Frequency 32MHz
Supply Voltage 3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2004
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 140.30179mg
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
