PIC16F1703-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MICROCHIP PIC16F1703-I/ST8 Bit Microcontroller, Flash, AEC-Q100, PIC16F17xx, 32 MHz, 3.5 KB, 256 Byte, 14 Pins, TSSOP
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $0.9416
≥100 USD $0.8712
Inventory: 1400
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2012
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3V
Frequency 32MHz
Base Part Number PIC16F1703
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.5/5V
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, LIN, RS-232, SPI, UART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 12
Nominal Supply Current 8μA
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, LINbus, SPI
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 3
Address Bus Width 8b
CPU Family PIC
Number of UART Channels 0
Number of ADC Channels 8
Number of I2C Channels 1
Dimensions
Height 1.05mm
Length 5.1mm
Width 4.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
